Product General Information:
| Place of Origin: | CHINA |
| Brand Name: | GRANDTECH |
| Model Number: | GTIS-7kw |
| Certification: | CE,ISO,UN38.3,ROHS,PSE,FCC,ETL |
| Warranty | 5 Years |
Product Business Terms:
| Minimum Order Quantity: | 2 |
| Price: | $478 EXW CHINA |
| Packaging Details: | ODM/OEM/BOX |
| Delivery Time: | 30 TIME |
| Payment Terms: | CIF/CFR/DDP/DPU/EXW |
| Supply Ability: | Fast shipping, factory shipped |
Description:
| item | value |
| Place of Origin | China |
| Zhejiang | |
| Brand Name | Grandtech |
| Model Number | GTI-U-3KW |
| System Energy | 3KW |
| Input Voltage | 220/230V |
| Output Voltage | 230Vac |
| Output Current | 60A |
| Output Frequency | 50Hz±0.3Hz/60Hz ±0.3Hz |
| Output Type | Single, Triple, Multiple |
| Size | 378L*280W*103D |
| Type | DC/AC Inverters |
| Inverter Efficiency | >95% |
| Certificate | CE,ISO,UN38.3,ROHS,PSE,FCC,ETL |
| Warranty | 1 years |
| Weight | 8KG |
Specifications：
| Model | GTIS-7KW | GTIS-8KW | GTIS-10KW |
| Maximum PV Input Power | 7000W | 8000W | 10000W |
| Rated Output Power) | 7200W/7200VA | 8200W/8200VA | 10200W/10200VA |
| Maximum Solar Charging Current | 160A | 160A | 160A |
| Nominal DC Voltage/Maximum DC Voltage | 360VDC/500VDC | ||
| Start-up Voltage/Initial Feeding Voltage | 90VCD/120VCD | ||
| Maximum DC Voltage | 90~450VDC | ||
| Number of MPPT Trackers/Maximum Input Current | 1/27A | ||
| Nominal Output Voltage | 200/230/240VAC | ||
| Output Voltage Range | 195.5~253VAC | ||
| Nominal Output Current | 31.3A | 35.6A | 44.3A |
| Power Factor | >0.99 | ||
| Feed-in Grid Frequency Range | 49~51Z±1Hz | ||
| Maximum Conversion Efficlency(DC/AC) | 98% | ||
| Full Load | 7200W | 8200W | 10200W |
| Maximum Main Load | 7200W | 8200W | 10200W |
| Maximum Second Load(battery mode) | 2400W | 2733W | 3400W |
| Main Load Cut Off Voltage | 44VDC | 44VDC | 44VDC |
| Main Load Return Voltage | 54VDC | 54VDC | 54VDC |
| AC Start-up Voltage/Auto Restart Voltage | 120-140VAC/180VAC | ||
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC | ||
| Maximum AC Input Current | 40A | 40A | 50A |
| Nominal operating frequency | 50/60Hz | ||
| Surge power | 14400W | 16400W | 20400W |
| Maxmum DC Voltage | 500VDC | ||
| MPPT Voltage Range | 90VDC~450VDC | ||
| Number of MPPT Trackers/Maximum Input Curent | 1/27A | ||
| Nominal Output Voltage | 220/230/240VAC | ||
| Oulput Waveform | Pure sine wave | ||
| Emiciency(DC to AC) | 94% | ||
| Nominal DC Voltage | 48VDC | 48VDC | 48VDC |
| Maximum Solar Charging Current | 160A | 160A | 160A |
| Maximum AC Charging Current | 140A | 140A | 140A |
| Dimension,DxWxH(mm) | 420*310*110 | ||
| Net Weighl(kgs) | 13.1 | 14.2 | 14.5 |
| Grass Weight(kgs) | 14.1 | 15.7 | 16 |
| Communication Port | RS232/WIFI/Remove LCD/GPRS | ||
| Operating Temperature | -10~50℃ | ||
Application: Toys
Application: Power Tools
Application: Home Appliances
Application: Consumer Electronics
Application: BOATS
Application: Golf Carts
Application: SUBMARINES
Application: Electric Bicycles/Scooters
Application: electric vehicles
Application: Electric Wheelchairs
Application: Electric Power Systems
Application: Solar Energy Storage Systems
Application: Uninterruptible Power Supplies
Competitive Advantage:
1.High quality
2.Factory delivery
3. Price concessions
4. Perfect after-sales support
SI CHUAN GRANDTECH NEW ENERGY TECHNOLOGY CO., LTD.Has been a professional and trusted new energy products supplier and service provider since 2016. We specialize in providing high-quality battery service and solar systems to businesses. we have been concentrating on offering the integrated power solution to our worldwide customers.
Room 1336, Block 1, No.77, Shun jiangSec, Wuhou Av. Wuhou District, Chengdu, Sichuan, China
