Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP

Product Description



Product Features
Warranty 1 years
Output Power 3KW
Output Type Single, Triple, Multiple
Size 378L*280W*103D
Output Current 80A
Input Voltage 220/230V
Model Number GTI-U-3KW
Weight 8KG
Brand Name Grandtech
Type DC/AC Inverters
Inverter Efficiency >95%
Output Voltage 230Vac
Output Frequency 50Hz ± 0.3Hz/60Hz ± 0.3Hz
Certificate CE,ISO,UN38.3,ROHS,PSE,FCC,ETL
Model GTI-U-3KW GTI-U-3.3K GTI-U-5K K GTIP-U-5K GTI-U-3.3K GTI-U-3K GTI-U-5K GTIP-U-5.5K GTI-U-8K GTI-U-10K
Rated input voltage 220/230Vac
Input voltage range (170Vac~280Vac)±2%/(90Vac-280Vac)±2%
Frequency Range 47±0.3Hz~55±0.3Hz (50Hz)/57±0.3Hz~65±0.3Hz(60Hz)
Switch time 10ms
Rated output power 3kw 3.3kw 5kw 5kw 3.3kw 3kw 5kw 5.5kw 8kw 10kw
Rated output voltage 230Vac
Output frequency range 50Hz±0.3Hz/60Hz±0.3Hz
Output voltage waveform Pure sine wave
Maximum Efficiency >92%
Battery voltage 24vdc 48vdc 48vdc 48vdc 48vdc 48vdc 48vdc 48vdc 48vdc 48vdc
Battery type Lead acid or lithium battery
PV operating voltage range 30-100vdc 60-145vdc 60-145vdc 60-145vdc 120-500vdc 120-500vdc 120-500vdc 120-500vdc 120-500vdc 120-500vdc
Battery voltage range 20-33vdc 40-60Vdc 20-33vdc 40-60Vdc
Maximum output power 1400w 3400w 4200w 4200w 4200w 4200w 5000w 5500w 11000w 11000w
PV charging current range (can be set)Charging short dircult 0-60A 0-60A 0-80A 0-80A 0-80A 0-80A 0-80A 0-80A 0-200A 0-200A
Parallel no no no yes,max 6pcs no no no yes,max 6pcs no no
Protection Undervoltage alarm/shutdown voltage/overvoltage alarm /overvoltage recovery... settable on LCD screen
Communication interface USB/RS485(WiFi/GPRS is optional)/Dry node control
Size (L*W*D)mm 378*280*103 378*280*103 498*410*201 498*410*201 378*280*103 426*322*126 426*322*126 426*322*126 717*507*210 717*507*210
Weight(kg) 8 12 12 12 8 12 12 12 26 26


Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP details
Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP details
Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP manufacture
Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP supplier
Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP details
Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP factory
Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP manufacture
Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP factory
Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP supplier


1. who are we?
We are based in Sichuan, China, start from 2018,sell to Mid East(40.00%),Eastern Europe(20.00%),Africa(20.00%),South Asia(20.00%). There are total about 5-10 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Wall Mounted Energy Storage, Stacked Energy Storage, Solar Inverters

4. why should you buy from us not from other suppliers?
null

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,FCA;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish,Russian

Introducing, the Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP by GRANDTECH. This all-in-one hybrid inverter is perfect for those who want to utilize solar power for their home or business.



The inverter includes a charged energy output of 4200W and can manage a maximum voltage of 500V. It was created to utilize a 48VDC battery and an input voltage of 220-230VAC. This will makes it something that is versatile and could work with different kinds of batteries.



One of the top features that come with this hybrid inverter is its capability to undertake up to 200A of cost rate, allowing it to charge the batteries quickly and effectively. It additionally comes with an MPPT (Maximum Power Point Tracking) function that guarantees maximum efficiency, converting solar power to electricity.



The hybrid inverter is sold with wifi capability so you can monitor its performance utilizing an software on your smartphone or tablet. This particular feature provides real-time data about the inverter's performance, making it simpler to optimize its performance.



Another great feature of this is its capacity to work as an off-grid inverter, meaning, it can operate independently through the grid. This is ideal for people who reside in remote areas with has limited access to electricity.



This hybrid inverter has multiple security features, including overcharge protection, over-discharge security, short circuit protection, and overheat security. These features help keep the inverter and your devices that are linked from harm.



GRANDTECH, the brand behind this hybrid inverter, is well known for its high-quality services and products and excellent customer support. This product is no exception since it was created using the latest technology and designed to provide dependable and efficient performance.



Overall, the Wholesale New EU Model 48VDC 220 230VAC PV 500V 4200W 3KW All In One Off Grid 200A MPPT Solar Hybrid Inverter with wifi APP by GRANDTECH is a great investment for those looking to harness the power of solar energy. With its impressive features and excellent performance, it is sure to exceed your expectations.

×
